500kW 625kVA Diesel Generator Set Weichai Engine 6M33D572E200
Product Overview
Our 500kW 625kVA BOBIG WEICHAI diesel generator (Model: 6M33D572E200) is engineered to deliver reliable power for diverse applications. Backed by the renowned Weichai brand, it offers superior performance and long-term durability.
Key Features
Power Performance
Rated Power: 500kW (625kVA) capacity suitable for industrial, commercial, and residential applications with stable prime power output.
Frequency: Standard 50Hz operation compatible with most electrical equipment.
Engine Excellence
Engine Model: 6M33D572E200 featuring advanced technology, high torque, fuel efficiency, and low emissions.
Engine Speed: 1500 RPM for smooth, consistent power supply with minimal component wear.
Technical Specifications
| General Information |
Prime Power |
Standby Power |
| Rated Power (kVA) |
625 |
688 |
| Power Rating (kW) |
500 |
550 |
| Frequency (Hz) |
50 |
| Engine Model |
6M33D572E200 |
| Engine Speed (RPM) |
1500 |
| Phase |
3 |
| PF |
0.8 |
| Control System |
Digital |
| Rated Voltage (V) |
400/230 (Customizable) |
| Fuel Tank Capacity Operating Time |
≥ 8h @ 75% load |
PRP: Prime power available for unlimited annual hours in variable load applications per GB/T2820-97; 10% overload capability available for 1 hour within 12-hour operation.
ESP: Standby power rating for emergency power supply during utility interruptions. No overload, utility parallel, or negotiated outage operation capability available.
Engine Details
| Engine Model & Manufacturer |
6M33D572E200 (WEICHAI) |
| Emission Certification |
---- |
| Number of Cylinders |
6 |
| Cylinder Arrangement |
In-line |
| Cycle |
L-Type |
| Aspiration |
Turbocharging and intercooling |
| Bore x Stroke |
150 x 185 mm |
| Cubic Capacity |
19.6 L |
| Compression Ratio |
15.0:1 |
| Prime Power/Speed |
520 kW/1500 rpm |
| Standby Power/Speed |
578 kW/1500 rpm |
| Governor Type |
Mechanical pump |
| Cooling System |
Force Water Cooling Cycle |
| Transient Frequency Deviation |
-0.833333333 |
| Total Lubrication System Capacity |
61 L |
| Coolant Capacity (Engine Only) |
43.93 L |
| Fuel Consumption @ 100% Load |
520 g/kWh @1500 rpm |
| Starter Motor |
DC 24V |
| Charge Alternator |
DC 24V |
Alternator Specifications
| Alternator Brand |
BOBIG |
| Alternator Manufacturer |
FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD |
| Alternator Model |
BW-354E |
| Alternator Rated Power |
500kW/625kVA |
| Rated Voltage |
230V/400V |
| Rated Frequency |
50Hz |
| Connecting Type |
3 Phase and 4 W |
| Number of Bearings |
1 |
| Protection Grade |
IP23 |
| Altitude |
≤1000m |
| Exciter Type |
Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper |
| Insulation Class |
H class |
| Telephone Influence Factor (TIF) |
≤50 |
| THF |
≤2% |
| Voltage Regulation, Steady State |
≤±1% |
| Transient State Voltage |
≤-15%~+20% |
Dimensions & Weight
| Model |
BWC688 (Open Type) |
BWC688S (Silent Type) |
| Length (L) mm |
3800 |
4300 |
| Width (W) mm |
1740 |
1400 |
| Height (H) mm |
2745 |
2200 |
| Tank Capacity (L) |
0 |
0 |
Environmental Adaptability
Ambient Temperature: Operational range of +5°C to +40°C.
Altitude: Suitable for use up to 1000m. Custom solutions available for different environmental conditions.
Applications
- Industrial Use: Backup power for factories to ensure continuous production during outages.
- Commercial Buildings: Power for office buildings, shopping malls, and hotels to maintain essential services.
- Residential Areas: Reliable power for communities with unstable power grids.
Warranty & Service
BOBIG products include a one-year or 1000-hour warranty (whichever comes first). During warranty, we provide free replacement of defective parts. After expiration, we offer cost-based spare parts and maintenance services with 24/7 technical support.
Why Choose Us
- Brand Reputation: Weichai is a trusted brand with a long history of quality products
- Quality Assurance: Manufactured to international standards with rigorous quality inspections
- Customization Options: Tailored solutions based on specific requirements
Frequently Asked Questions
What is your MOQ, payment method, delivery time?
MOQ: 1 set. Payment: 30% T/T deposit, 70% balance before delivery, or 100% L/C, trade assurance, PayPal, Western Union. Delivery: 10-15 working days after deposit receipt.
Which port do you often use when export?
Fuzhou port, Fujian province or as customer request.
Is there any spare parts you can provide along with generators?
We provide regular engine air filter, water filter, fuel filter, and oil filter for self-maintenance.
Can you offer parts to us if we need?
Yes, we can provide parts at any time, typically shipped within 3-5 days.
Can you customize voltage, frequency, tank capacity, phase and color?
Yes, all specifications can be customized according to your requirements.
What is your distribution policy?
We welcome distributors worldwide and can issue authority certificates and sign agreements accordingly.
