Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby

Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Toldo: Personalizado
Garantía: 12 meses/1000 horas
Tipo: Silencioso (súper silencioso) o abierto, silencioso, etc., en línea/6 cilindros/4 tiempos/4 válvulas
Panel de control: Pantalla digital LCD, Deepsea, ComAp, Deepsea / ComAp / Harsen / Smartgen 6110, Smartgen
Tipo de salida: CA monofásica/trifásica
Controlador: Mar profundo/Smartgen/etc.
Solicitud: Banco industrial, etc.
Tensión nominal: 400/230 V, 110-480 V, 220 V/380 V, 110 V/240 V, 380 V
Alternador: Marathon, Stamford, SLG/Stamford/Marathon/Meccatle/Leroy-somer, Stamford o Newtec, Engga
Nombre del producto: Generadores diésel PERKINS 640kW 800KVA personalizables, para uso doméstico, industrial, hospitalari
Color: Requisito de los clientes
Frecuencia: 50/60Hz
Potencia nominal: 800kVA
Motor: Perkins original
método de enfriamiento: Sistema de refrigeración por agua
Resaltar:

3 phase diesel generator 800KVA

,

silent genset for home use

,

portable standby Perkins generator
Información básica
Lugar de origen: Porcelana
Nombre de la marca: PERKINS
Certificación: CE
Número de modelo: 4006-23TAG3A (India)
Pago y Envío Términos
Detalles de empaquetado: madera contrachapada
Tiempo de entrega: 30 dias
Capacidad de la fuente: 500 unidades por mes
Descripción de producto
640kW 800KVA BOBIG PERKINS Diesel Generator
Model: 4006-23TAG3A (India) - Reliable Power Solution
Our 640kW 800KVA BOBIG PERKINS diesel generator is designed to provide reliable power for a wide range of applications. Backed by the renowned PERKINS brand, it offers high-quality performance and long-term durability.
Key Features
Power Performance
Rated Power: 640kW (800KVA) for various industrial, commercial, and residential applications
Frequency: 50Hz standard frequency suitable for most electrical equipment
Prime Power: Stable and efficient output ensuring continuous operation under heavy loads
Engine Excellence
Engine Model: 4006-23TAG3A (India) PERKINS engine
Engine Speed: 1500 RPM for smooth and consistent power supply
Features: High torque, fuel efficiency, and low emissions
Technical Specifications
General Information Prime Power Standby Power
Rated Power (kVA) 800 880
Power Rating (kW) 640 704
Frequency (Hz) 50
Engine Model 4006-23TAG3A
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated Voltage (V) 400/230 (Customizable)
Fuel Tank Capacity Operating Time ≥ 8h @ 75% load
Dimension and Weight
Model BP880 (Open Type) BP880S (Silent Type)
Length (mm) 4500 5600
Width (mm) 1800 2200
Height (mm) 2745 2550
Tank Capacity (L) 1472 1472
Engine Specifications
Engine Model & Manufacturer 4006-23TAG3A (PERKINS)
Number of Cylinders 6
Cylinder Arrangement Vertical Inline
Cycle Four Stroke
Aspiration Turbocharged
Bore x Stroke 160 x 190 mm
Cubic Capacity 22.921 L
Compression Ratio 13.6:1
Prime Power/Speed 705 kW/1500 rpm
Standby Power/Speed 786 kW/1500 rpm
Cooling System Force Water Cooling Cycle
Fuel Consumption (100% load) 210 g/kWh @1500 rpm
Alternator Specifications
Alternator Brand BOBIG
Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-404C
Rated Power 640kw/800kva
Rated Voltage 230v/400v
Rated Frequency 50hz
Connecting Type 3 Phase and 4 W
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class H class
Voltage Regulation, Steady State ≤±1%
Applications
  • Industrial Use: Backup power source for factories ensuring continuous production
  • Commercial Buildings: Office buildings, shopping malls, and hotels for essential services
  • Residential Areas: Reliable power for communities with unstable power grids
Certifications & Standards
Our generator complies with international standards including ISO 8528-5:2018, GB/T2820.5-2009, and CE certification.
Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 0 Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 1
Customization & Services
• Customization and OEM services available with design drawings
• Standard DSE 6120 controller included (engine, generator, and controller options available)
• One-year or 1000-hour warranty (whichever comes first)
• Professional after-sales service team available 24/7
Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 2
Company Information
We are an electrical machinery manufacturer with 10,000 square meters factory area, 160 employees, and 20 technicians. Our main products include gasoline generators, diesel generators (5-2000kva), gas generators, and pumps.
Factory & Facilities
Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 3 Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 4
Production & Testing
Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 5 Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 6 Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 7 Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 8
Packaging & Shipping
Plywood case packaging, 10-15 working days delivery after receiving customer deposit.
Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 9 Inverter Generator 3 Phase Power Generators 640kW 800KVA Silent Genset diesel Generator for Home Use Portable Standby 10
